Spade terminals are designed for reliable electrical and grounding applications. They are available in various lengths, widths, and thicknesses. Standard configurations range from 2-hole to 20-hole designs, with custom sizes available upon request.
We offer in-line or “G” spade styles, with or without tangs (anti-rotation devices). Available in both imperial and metric dimensions, these spades provide secure connections for various
Material Options:
Applications:
Standard Features:
Customization Options:
Technical Specifications:
| Parameter | Specification |
| Material | Copper, Aluminium, Brass, Stainless Steel |
| Coating Options | Tin-Plated, Nickel-Plated, or Bare Metal |
| Thickness | Varies based on application (customizable) |
| Hole Configurations | 2-hole to 20-hole (custom configurations available) |
| Bolt Size Compatibility | M6, M8, M10, M12, or customized |
| Operating Temperature | -55°C to +150°C |
| Corrosion Resistance | High, with optional protective coating |
Standard Size Range for Spades:
| Length (mm) | Width (mm) | Thickness (mm) | Hole Diameter (mm) | Hole Count |
| 50 – 100 | 20 – 40 | 2 – 3 | 8 | 2 – 4 |
| 101 – 200 | 30 – 60 | 3 – 5 | 10 | 4 – 10 |
| 201 – 400 | 40 – 80 | 5 – 10 | 12 | 10 – 20 |
For more details, please contact Royal Brass Products for pricing, bulk orders, and custom requirements. Royal Brass Products ensures top-notch service and unparalleled product quality.
